Large Scale Fabrication

Our expertise includes cutting, coping, notching, beveling, and etching for projects in virtually any material. Using advanced CNC programming, we can cut through steel up to 12 inches thick and handle up to 2,500 linear feet of 1/2-inch carbon steel in a single day. With three-torch capabilities, we deliver five-axis bevel-headed cuts, straight cuts, and precise high-definition edging with exceptional accuracy.

Our hot wire GTAW cladding services provide a highly versatile weld overlay for those applications that require corrosion-resistant properties. Our high deposition rate — 16 pounds per hour in flat position, three pounds per hour in horizontal — gives us the ability to complete projects with greater efficiency, without sacrificing quality.

Having stress relief performed on-site helps shorten lead time and increase efficiencies while improving the stability of your components. Our thermal processes include heating parts up to 1300 degrees Fahrenheit for parts up to 30,000 pounds to achieve stability, reduce hardness and improve machinability; while our vibratory process can quickly stress relieve stainless steel and other alloys without altering the molecular makeup.

We have six Collaborative Welding Robots (Cobots) that perform all the same welding processes and capabilities, but in a smaller footprint than a conventional robot. We use advanced programming techniques and functions to place the weld in the joint, such as Touch Sensing, Thru-Arc Seam Tracking (TAST), and Multi-Pass offsets to accurately and repeatedly perform critical welds.

We also use conventional Industrial Welding Robots to perform welding along with Extended and Auxiliary axes to position parts in an ideal position for welding as well as increase the usable footprint of the robot.

Our 110” cube New Generation Electron Beam Welding System can handle the job when your application requires deep penetration and low distortion performed to precise specifications.

This system can accommodate small to large parts that specifically require EB welding. The CNC-controlled unit can weld dissimilar metals that require deep penetration into the material to create high-purity welds with minimal distortion. The result is a clean, precise weld, every time.

With one of the largest high-tonnage press brakes, we can tackle large-scale projects with up to 4,400 tons of force, delivering the precision and strength needed for heavy-duty applications. For smaller-scale jobs, our 250-ton press brakes are used to expertly bend metal up to ten feet in length, ensuring accuracy and flexibility across a wide range of projects.

We’re able to roll metal into various sizes and profiles, enabling the production of durable, high-performance components. Whether for large infrastructure projects, complex machinery, or specialty applications, we’re able to deliver customized solutions that meet exact specifications. Through advanced rolling techniques, we can create beams, plates, angles, and more with unparalleled consistency, ensuring strength, reliability, and flexibility for the most demanding environments.
